Stationary Bandsaws
ABS 1750XL
Bandsaw with column - Independent Down Feed
Max 160 mm
| Article | Code |
|---|---|
| ABS 1750XL | 8486091 |
Cutting capacity
 |
 |
 |
|
|---|---|---|---|
| 0° | 160x140 mm | 155 mm | 150x150 mm |
| 45° | 100x120 mm | 110 mm | 100x100 mm |
| Arm downfeed | Automatic |
|---|---|
| Blade development (mm) | 1735 |
| Motor power (watt) | 2000 |
| Electrical supply (Volt-Hz) | 230 - 50 |
| Weight (Kg) | 75 |
| Blade speed (mt/min) | 35÷80 Digital electronic speed regulator Constant Speed |
| Toothing Z/1" | 8/12 |
| Packaging (mm) | 780x1240x1080 |
| Lubrication | Sì |
Technical features
Push-Click System with mechanical selector and automatic cut-off switches
- Integrated lubrificating system, easy to adjuste for cutting pieces of differente sizes
- Sliding rolls for supporting in-ad out-going wordpieces
- Safety emergency button to stop cutting
- Blade tensioning dvice cluch to achierve the proper blade tension (PATENTED)
- Energy saving 100% motor efficiency is granted by exclusive ABS System
Standard equipment
Column in assembly kit
- Removable Tank for lubricating oil
- Lubricating pump
- Bar stop-rod for mass-produced cuts
- Sliding rolls for supporting both in- and out-going workpiece
